3-Button LED Motorcycle Handlebar Switch

3-Button LED Motorcycle Handlebar Switch

The MessnerMoto 3-Button LED Motorcycle Handlebar Switch combines three illuminated controls in an ultra-slim 12 mm wide CNC-machined housing. Designed for 22 mm (7/8″) handlebars, the switch is machined from 6061-T6 billet aluminum and finished in hard-anodized satin black. Three IP65 momentary push buttons provide compact control for functions such as indicators, horn, high beam, starter or other custom electronics, while integrated LEDs can be used as visual indicators. Each button comes pre-soldered with 30 cm (12″) of 26 AWG wire, making installation and internal handlebar routing easier.

Ultra-Slim 12 mm CNC Design

At only 12 mm wide and 45 mm in diameter, the switch keeps handlebar space and visual bulk to a minimum. The compact housing works particularly well with café racers, custom motorcycles, restomods and minimalist cockpit builds, where conventional switchgear can look oversized. Each housing is precision CNC-machined from 6061-T6 billet aluminum, finished with a fine satin surface and protected by hard black anodizing.

Three Illuminated Push Buttons

The switch uses three momentary LED push buttons, allowing the controls and indicator functions to be configured around your motorcycle’s electrical system. Depending on your setup, the buttons can be used for functions such as:

• Turn signals
• Horn
• High / low beam
• Starter
• Mode or auxiliary functions

The integrated LEDs can also be configured as visual indicators for functions such as turn signals, high beam, neutral or warning lights, depending on your wiring and control system. Available LED colors allow the switch setup to be matched to the function and cockpit design.

Designed to Use Without Looking

Each button has a 12mm outer diameter with an 5mm clickable surface. A 10mm physical separation between the buttons helps distinguish each control by touch, making the switch easier to operate while wearing motorcycle gloves without needing to look down at the handlebars.

Pre-Wired with 26 AWG Wire

Each LED button now comes with 30 cm (12″) of 26 AWG wire pre-soldered, reducing installation work and eliminating the need to solder directly onto the miniature button terminals. The wiring can be shortened, extended or integrated into your motorcycle’s wiring harness depending on the installation.

Internal or Side-Exit Wiring

For the cleanest possible cockpit, the wiring can be routed internally through the handlebars or clip-ons. For builds where internal routing isn’t practical, the housing also supports external side-exit wiring. This flexibility makes the switch suitable for both completely hidden wiring installations and more conventional custom motorcycle electrical layouts.

Compatible with Motogadget mo.unit & Custom Electronics

The momentary push-button design makes the switch suitable for modern motorcycle control systems such as the Motogadget mo.unit, as well as other compatible electronic control modules and custom electrical systems. When used with a compatible control unit, the three buttons can operate multiple motorcycle functions while keeping the handlebar controls extremely compact. Always follow the wiring requirements of your motorcycle or electronic control module when assigning button and LED functions.

Built for Minimalist Motorcycle Cockpits

The compact design is particularly suited to café racers, custom motorcycles and modern-retro builds, including BMW Airhead and K-series customs, Honda CB builds, Triumph Bonneville projects, Royal Enfield Continental GT 650 and Interceptor 650 builds, Yamaha XS/XSR projects and other motorcycles using 22 mm handlebars or clip-ons.

Fitment depends primarily on the 22 mm / 7/8″ handlebar diameter and available mounting space, rather than the motorcycle model itself.

Complete Your Cockpit

Pair the switch with MessnerMoto CNC clip-ons, motorcycle throttles, bar end mirrors and radial master cylinders to create a clean cockpit with consistent materials, finishes and design language.



Weight	0.1 kg
Color	Black, Silver
Side	Left(Clutch Side), Right(Brake side)
